Hilo3d

A WebGPU-first, TypeScript-first 3D engine with a production WebGL 2 compatibility backend.

Hilo3d vNext is designed around a WebGPU-shaped rendering hardware interface (RHI), explicit render passes, reusable GPU resources, GLSL ES 3.00, physically based rendering, and glTF. WebGPU keeps its native pipeline/bind-group/command model, while WebGL 2 implements the same portable subset through immediate, state-cached GL execution.

WebGPURHI is a thin mapping to native WebGPU objects and commands; it does not become a GL-style state machine and does not replay a second JavaScript command buffer.
WebGL2RHI emulates pipeline, bind-group, render-pass, and command-encoder semantics while issuing GL calls immediately through a state-diff cache. finish()/submit() are ownership boundaries, not a deferred replay path.
GLSL ES 3.00 is the only authored shader source. The Renderer shader compiler resolves variants and translates WebGPU modules through Naga before the RHI sees them.
Backend policy is explicit: auto performs a capability-based choice, while an explicit webgpu or webgl2 request is never changed silently.

Install

npm install hilo3d

The package has one ESM entry point for modern bundlers and native browser ESM. WebGL 1, CommonJS, UMD, and global-script builds are not part of the vNext contract.

WebGPU quick start

Stage.create() defaults to backend: 'auto', prefers WebGPU when a compatible adapter is available, and waits for the selected backend to become ready. The returned stage is ready to render.

import * as Hilo3d from 'hilo3d';

const camera = new Hilo3d.PerspectiveCamera({ aspect: innerWidth / innerHeight, z: 4 });

const stage = await Hilo3d.Stage.create({
    backend: 'webgpu',
    container: document.querySelector('#app')!,
    camera,
    width: innerWidth,
    height: innerHeight
});

const box = new Hilo3d.Mesh({
    geometry: new Hilo3d.BoxGeometry(),
    material: new Hilo3d.PBRMaterial({
        baseColor: new Hilo3d.Color(0.832, 0.119, 0.093)
    })
}).addTo(stage);

stage.addChild(new Hilo3d.AmbientLight({ amount: 1 }));

const ticker = new Hilo3d.Ticker(60);
ticker.addTick(stage);
ticker.start();

Omitting backend is equivalent to backend: 'auto'. Auto selection calls Renderer.isBackendSupported('webgpu', options) first. This lightweight probe only requests an adapter and validates the fallback-adapter policy, required features, required limits, and Hilo3d's minimum adapter limits. It does not request a device, acquire a canvas context, initialize Naga, create a pipeline, or allocate GPU resources. A compatible adapter selects WebGPU; otherwise Stage.create() creates WebGL 2 directly. Supplying the WebGL2-only preserveDrawingBuffer option also makes auto selection choose WebGL 2 directly, as does requesting straight-alpha canvas compositing with alpha: true, premultipliedAlpha: false.

Once the probe selects WebGPU, normal WebGPU initialization runs exactly once. A device or canvas context error, shader-compiler failure, pipeline/resource initialization error, or any later failure rejects Stage.create() and is never caught as a reason to fall back. Requesting backend: 'webgpu' skips the auto probe and likewise never falls back.

Applications can use the same device- and GPU-resource-free probe without creating a renderer:

const webgpuSupported = await Hilo3d.Renderer.isBackendSupported('webgpu', {
    powerPreference: 'high-performance'
});

WebGL 2 compatibility

Use the compatibility backend without changing scene, material, render-target, or GLSL code:

const stage = await Hilo3d.Stage.create({
    backend: 'webgl2',
    container: document.querySelector('#app')!,
    camera
});

Stage is created only through the asynchronous Stage.create() factory, including when WebGL 2 is selected explicitly. Hilo3d never creates a WebGL 1 context.

Creating a renderer directly

Renderer is the only public renderer class and is created exclusively through the asynchronous Renderer.create() factory:

const webglRenderer = await Hilo3d.Renderer.create({
    backend: 'webgl2',
    domElement: document.querySelector('canvas')!
});

const autoRenderer = await Hilo3d.Renderer.create({
    backend: 'auto',
    domElement: document.createElement('canvas')
});

const webgpuRenderer = await Hilo3d.Renderer.create({
    backend: 'webgpu',
    domElement: document.createElement('canvas')
});

Every renderer creates the same public RenderTarget contract. Backend selection is observable through renderer.backend; it does not change the scene, material, target, or shader API.

Capability matrix

Capability	WebGPU	WebGL 2
RHI execution	Thin native encoder/pass/queue mapping	Immediate GL execution behind encoder/pass semantics
Shader module input	Renderer-prepared WGSL	Renderer-prepared GLSL ES 3.00
Multi-pass `renderFrame`	One encoder/submit for resource-ready renderer passes	Ordered immediate execution; submit never replays commands
Device-object reuse	Bounded pipeline, layout, and sampler caches	Bounded pipeline, layout, sampler, framebuffer, and VAO caches
Incremental uploads	UBO/geometry dirty ranges; texture revisions	UBO/geometry dirty ranges; texture revisions
Render targets	MRT, 1×/4× MSAA, sampled attachments, async readback	Same engine contract
Unsupported RHI features	Reported through `features`/`limits`; rejected when requested	Compute/storage/1D/async buffer mapping report unsupported
Loss handling	Device reacquisition and resource recovery	Context restoration and resource recovery
Backend selection	Explicit requests reject; `auto` uses an adapter-only probe	Selected directly when the `auto` probe is unsupported

One frame, multiple passes

Use renderFrame() for an application-owned frame graph. On WebGPU, resource-ready scene, target, and present calls in the callback share one application command encoder and finish with at most one application submission. WebGL 2 executes the same commands in order through the same backend-neutral facade.

const reflectionTarget = renderer.createRenderTarget({
    width: renderer.width,
    height: renderer.height
});
const sceneTarget = renderer.createRenderTarget({ width: renderer.width, height: renderer.height });

renderer.renderFrame(frame => {
    frame.renderToTarget(reflectionTarget, stage, reflectionCamera);
    frame.renderToTarget(sceneTarget, stage, camera, true);
    frame.present(sceneTarget);
});

Resize application-owned targets when the renderer size changes. Use this frame callback from a custom tick instead of also letting Stage perform its default render. The callback is synchronous: do not return a Promise or retain its frame facade. Settle scene transforms, material values, GeometryData, and texture updates before entering it; geometry and texture content cannot change after first use in the same frame. Cold texture mipmap preparation and explicit readback are separate GPU work and are not counted as application-pass submission. Run renderer resize/setRenderTarget()/resource release/destruction and render-target resize/readback/destruction outside the callback; attempting those operations while WebGPU is recording aborts the entire frame and prevents a partial submission.

Scriptable render pipelines

Pass a reusable renderPipeline factory to Renderer.create() or Stage.create() to replace frame composition, or use ForwardRenderPipelineFactory features to inject work around shadows, opaque, transparent, post-process, and output stages. Each Renderer receives independent pipeline and feature runtimes; recording stays synchronous and writes into the same transactional Render Graph as ordinary renderer commands. The empty default feature set keeps the original direct forward path, without an intermediate scene target or an extra present pass.

Graph sampling and texture copies use distinct declarations: fullscreen inputs must be linear-filterable, while copy passes declare an exact source/destination pair and validate the resolved RHI textures before a backend frame begins.

The scriptable pipeline example samples scene color through a retained fullscreen feature. The SRP architecture document covers ownership, failure handling, performance gates, and the capability-gated route to storage buffers and compute. Those compute/storage capability names are currently fail-closed rather than partially emulated on WebGL 2.

Modern renderer architecture

src/render owns the single public Renderer, scene traversal, frame planning, render-target contracts, std140 uniform data, shader-interface preparation, and deterministic engine-resource ownership.
src/shader owns authored GLSL preprocessing and engine shader variants; src/render/shader reflects bindings and performs GLSL-to-WGSL compilation. RHI code never knows what a shader variant or material is.
src/render/rhi/RHI.ts defines the portable WebGPU-shaped device, resource, pipeline, bind-group, render-pass, encoder, queue, surface, feature, and limit contracts.
src/render/rhi/RHIFactory.ts is the single hardware composition root. It constructs one concrete RHI and owns backend support probes; it does not wrap that RHI in a per-command facade.
src/render/rhi/backends/webgpu directly wraps native WebGPU. src/render/rhi/backends/webgl2 contains the WebGL 2 emulation, state cache, framebuffer/VAO ownership, and context recovery. Neither RHI backend imports engine scene types.
Backend-specific preparation and native execution remain internal implementation details; there are no backend-specific public Renderer or RenderTarget classes. The internal Renderer factory selects a concrete driver once during construction and returns it directly.

The abstraction boundary intentionally follows WebGPU rather than the WebGL state machine. A WebGPU render pass maps one-for-one to its native pass, and a WebGPU command encoder owns the native encoder directly. WebGL2RHI applies pipeline and bind-group state only when it changes and executes draw/copy commands during encoding; the returned command buffer is a single-use submission token. Production WebGPU paths use one-hop native fast paths on that same concrete device, so the main draw loop keeps native handles and pays no per-draw wrapper or virtual-dispatch cost. The WebGL 2 path runs its Program/VAO work in a frame-scoped session backed by the RHI's single context, canonical state differential, lifecycle, and device-owned sampler cache. Program, VAO, and framebuffer caches remain render-layer caches; it never creates a parallel context or a replayable command list. Capabilities that do not have a sound WebGL 2 implementation—including compute pipelines, storage textures, storage buffers, 1D textures, asynchronous buffer mapping, base-vertex draws, and first-instance draws—are absent from its features or exposed as zero limits and fail explicitly when requested. Inside the RHI contract, per-format sampling, filtering, attachment, storage, and MSAA support is reported conservatively, including extension/tier-dependent differences.

Every engine shader starts as GLSL ES 3.00. WebGL 2 compiles it directly. WebGPU resolves the shader variant, rewrites its active interface to Vulkan GLSL 4.50, and passes it through the Naga WASM frontend to produce WGSL. Engine utility passes use the same path; there is no handwritten fallback WGSL shader set.

Shader variants use a structured, type- and length-delimited dual-lane 64-bit hash without an intermediate serialized key. Exact fields are retained for collision checks, so a collision receives a deterministic bucket key instead of aliasing another shader. Cache ownership is deliberately single-layered: each RHI device owns bounded immutable sampler, bind-group-layout, pipeline-layout, and render-pipeline caches; the Renderer owns material, Mesh, shader-variant, binding-set, and upload revision caches. Buffers, textures, shader modules, and bind groups are never descriptor-deduplicated by the RHI because their identity and lifetime are application data. Labels do not participate in device cache keys. Device loss/context restoration and explicit destruction clear every device cache.

Texture identity is backend-neutral: the shared object stores CPU content, immutable update snapshots, and monotonic revisions only. Each WebGL context and WebGPU device owns its native allocations and upload cursor. WebGL descriptor snapshots preserve stable native objects across framebuffer resize/reset; WebGPU defers destruction of buffers and textures referenced by a pending submission. Internal lifecycle observers release every backend allocation before cancellable public events run, including device/context loss and explicit resource release. WebGL sampler variants are immutable, bounded, and bound per texture unit, so one depth texture can be read numerically and through a comparison sampler in the same draw without mutating global texture state.

Render-target owners track attachment allocation generations on both backends. Texture target changes, failed uploads, and explicit attachment destruction invalidate the previous allocation; the target rebuilds or reattaches before reuse and rejects stale native handles.

Uniform buffers, dynamic geometry, and textures carry backend-local revisions. Both backends upload only merged UBO and geometry dirty ranges when allocation shape is stable, while textures replay immutable subresource-update snapshots from the required revision. WebGPU command-state caching also suppresses repeated pipeline, bind-group, vertex/index buffer, viewport, and stencil commands within a pass.

Custom GLSL and UBO contract

Numeric shader data belongs in registered std140 blocks. Samplers are the only uniforms allowed outside blocks.

Hilo3d.registerUniformBlockBinding('EffectBlock');
const effectLayout = Hilo3d.createStd140Layout({ tint: 'vec4' });
const effectBlock = Hilo3d.UniformBuffer.fromSchema(effectLayout, {
    tint: [0.6, 0.8, 1, 1]
});

const material = new Hilo3d.ShaderMaterial({
    attributes: { a_position: 'POSITION' },
    uniformBlocks: { EffectBlock: effectBlock },
    vs: `#version 300 es
layout(std140) uniform EffectBlock { vec4 tint; };
in vec3 a_position; out vec4 v_tint;
void main() { v_tint = tint; gl_Position = vec4(a_position, 1.0); }`,
    fs: `#version 300 es
precision highp float;
in vec4 v_tint; layout(location = 0) out vec4 outColor;
void main() { outColor = v_tint; }`
});

effectBlock.set('tint', [1, 0.5, 0.2, 1]);

Use in/out, texture(), and explicit fragment outputs. Register each custom block before first use, keep same-name block layouts identical across stages, and use flat schemas of scalars, vectors, matrices, or fixed arrays.

Device and resource lifecycle

WebGPU device loss emits webgpuDeviceLost, reacquires an equivalent adapter/device with the frozen requirements, revalidates features and limits, rebuilds device-owned managers and caches, restores render-target resources without changing their public object identity, and emits webgpuDeviceRestored. Frames are skipped while recovery is active. Terminal recovery emits webgpuDeviceRecoveryFailed; later renders throw that error and the renderer never switches to WebGL 2. releaseGPUResources() clears owned GPU state while leaving the renderer reusable.

Use await renderer.waitForIdle() when application code needs a backend-neutral completion fence. Native interoperability is opt-in through renderer.getExtension('webgl2-native') or renderer.getExtension('webgpu-native'); native contexts and devices are not fields on the public Renderer. Always capability-check an extension before using it, and keep normal rendering on the shared Renderer/RenderTarget API.
